Kinman 7 String P 90 Hx - Zero-Hum Guitar Pickups

Kinman Custom Shop 7 String P-90 Hx Zero-Hum

Our New Universal Black Soapbar cover

Hand buffed Nickel-Silver soapbar cover

NEWS Flash 18-August-2022: We now supply our new 'Universal' soapbar covers in genuine Gibson Cream, Warm White, Old Ivory and Black, click your preferred option when ordering.

Zero-Hum & 100% Tone

Kinman Custom Shop Zero-Hum 7 String Soapbar P-90.

Do you have lust for a 7 string custom build guitar that is different to any other? In a world dominated by murky sounding humbuckers we believe these are the first Zero-Hum P-90 Soapbar 7 string pickups to become available. Design your guitar with normal Soapbar cavities and get creative with it's controls, remember a single 250k volume control and a mahogany body & neck is the way to go.

As beautifully engineered on the inside as is visually beautiful on the outside, and also there is the beautiful dynamic sound. But don't let the beautiful description cause you to think these pickups can't cause sonic mayhem, they certainly have that capability ... and in the hands of a competent player can be more brutal and dynamic than any humbucker.

The naturally lush, super dynamic sound, rapid attack and clarity of a Kinman P-90 Hx is eminently suited to the drop tuning of a 7 string guitar and our Bright Sweet Neck, Bright Clean Bridge, Bright C&B Neck and Bright Nasty 90 models will find a home in heavy metal, progressive rock, jazz and any other type of music you care to name.

Each one will have your name engraved on the baseplate with a serial number beginning with 001.

We would love to make some for you, and we can make them in different sounds too. These are not a production pickup but originals, painstakingly hand crafted from specially made component parts of high performing exotic materials.

We can also make 7 String Humbuckers as well as 7 String Strat pickups in a variety of different models.

We'd love to hear from you so stop dreaming and go ahead and Message us and let's get to talking about your dream 7 string pickups from Kinman's Custom Shop.

Pickup adjustment

As with all Kinman Gen-2 pickups these are very sensitive to height adjustment. A good starting point, so the neck and bridge pickups balance, is with the two E strings fretted at the 15th fret, adjusted as follows ...

bridge pickup so the string-to-magnet gap is 1.25mm for both E strings
neck pickup so the string-to-magnet gap is 1.5mm for both E strings

Installation

Consider including our optional non-magnetic mounting plate kit, it makes install fast n easy because you don't have to drill holes in the precise position for the pickups mounting screws in cavity floors because it also acts as a drill guide. Being non-magnetic our plate will not compromise the hum cancelling ability of the P-90 Hx.

Connections

Bare wires for soldering.
Kinman connectors for plugging into a Kinman Strat, Tele or KHP-90 No-Soldering harness.

Output Polarity:

in-phase with Gibson and Copy humbuckers
in-phase with all other Kinman pickups
opposite phase to Fender Strat
Fender pickups have opposite output polarity so consider Kinman's Strat models which have same output polarity.

Pot & Capacitor values

Best with 250k Ohm for Volume. Many Gibson's have 300k whichis fine also.
Normal Tone pot is 500k however to maximize clarity use a No-Load or alternatively a 1 Meg Ohm tone pot.
Normal tone cap value of 0.022µF in 63 ~ 100 volt Polyester. Smaller value lessen the severity of Treble cut, higher values increase it.

Cavity depth

No need to deepen the pickup cavity in ANY guitar that has flat bottom cavities for P-90's.

Pole spreads

53mm pole spread for bridge position of Stratocasters or with any bridge having saddle spread of 54+mm.
50mm for Gibsons or bridges having saddle spread of 50mm ~ 54mm.
47.5mm for neck position of Gibsons or or guitars that have 52mm spaced bridge

Covers

Nickel-Silver Soapbar covers in 47.5mm, 50 and 53mm.
Plastic Soapbar cover available for 47.5mm, 50 and 53mm pole spreads available in Black & Cream only.
Plastic Soapbar covers with 50mm pole spread available in White, Black, Cream and Chrome.
Not suitable for Dog-Ear covers

Hook-up cable

The P-90 Hx has 3 conductor cable so it's phase reversible to match any other pickup.
Length is 380mm / 15".

Mounting hardware

2 Long mounting screws.
2 Silicon Rubber tube springs.
handy drill guide template for positioning the screw holes in the virgin floor of the pickup cavity of a project guitar or guitars with freshly deepened cavities.
OPTIONAL extra: Soapbar cavity mounting plate, including all screws and springs. It's non-magnetic and won't interfere with hum cancellation.

Sorry, No accolades for this pickup.
